Tunable Cob Led Strip Lights 10MM/ 12MM DC24V CRI: 90 2700+6500K
10W Flexible Soft Light Strip
Product Description
Product Information |
Product Model | Tunable Flexible Led Cob Strip light |
FPC Width | 10MM /12MM |
Power | 10w+10w |
Voltage | DC24V |
Color Temperature | 2700K+6500K |
LEDs/ Meter) | 512Leds 576 Leds |
CRI(Ra) | 90 |
Packaging Details | 5 Meter/ Roll |
Product features
①Pure color: with the advantages of LED luminous components, pure
light color/soft/no dazzle light.
②Flexibility: using very soft FPC substrate, can be bent greatly,
easy to form, suitable for all kinds of
decoration and lighting.
③Low heat: luminous components are LED chips. The power of a single
LED chip is generally less than
0.03w, and the heat of a single LED chip is very low.
④Energy saving: compared with traditional lighting and decoration,
the power is reduced several times, and
the lighting effect is greatly enhanced.
⑤Environmental protection: no matter LED light source or FPC base
material, all accord to ROHS standard.
⑥Safety: the led light bar uses the low voltage dc 12/24v power
supply voltage.
⑦Easy to install, LED light bar with clamp, trough, iron net, etc
can be installed in all kinds ofbearing surface,
in addition, due to soft and thin, also can use the double-sided
adhesive to realize the function of fixed, no
need professional installation.
⑧Long service life: the normal service life of LED soft light bar
is 50,000-100,000 hours, which is several
times of the life of traditional lamps.
Product characteristic parameters
| Company abbrevi ation | Product si ze (mm) | Input v oltage (V) | Series- paralle l | Half a meter powe (W) | Half-meter shear group numbe | Emitting color | CRI | Photosyn thetic efficiency level (lm/w) | Packag e stand ard | Color t oleran ce |
| XC | 12 | 24 | 0836 | P10 | J18 | 27 | 90 | B | B2 | S3 |
(xuancai) |
500*12mm |
DC24V |
08-C 36-B |
10W |
18 |
2700K |
＞90 |
100-110 |
(Blister box) |
≤3 |
| XC | 12 | 24 | 0836 | P10 | J18 | 65 | 90 | C | B2 | S3 |
(xuancai) |
500*12mm |
DC24V | 08-C 36-B |
10W |
18 |
6500K |
＞90 |
110-120 | (Blister box) |
≤3 |
Reliability test standards
(A pilot project) |
(Number of test) |
(Test conditions) |
(Decision criteria) |
(Test Vequipment) |
| Cold and hot shock |
10pcs |
-40℃/30min -- 120℃/30min, one Cycle per hour, 100 cycles in total. |
No glue crack/dead light | Cold and heat shock chamber |
| The normal temperature aging |
10pcs |
Ambient temperature 25±5℃, rated voltage /1000hr, 168H to test the
photoelectric parameters once. | 1. Droop 10% or less 2.No glue crack/dead light | Normal temperature aging block |
| High temperature and high humidity |
10pcs |
Ambient temperature 85±5℃, rated voltage /1000hr, 168H to test the
photoelectric parameters once. | 1. Droop 10% or less 2.No glue crack/dead light |
High temperature and high humidity aging tank |
Application
